## Voltage Divider Calculator

Source Voltage | |
---|---|

R1 Value | |

R2 Value | |

R3 Value | |

Voltage Across R2 | V |

Voltage Across R3 | V |

**Voltage Divider Information:** A voltage divider is a circuit that uses two resistors to divide the input voltage (Vs) into a smaller output voltage (Vout). The output voltage is proportional to the ratio of the two resistor values. Online Voltage Divider Calculator

A voltage divider is a fundamental circuit used in electronics to produce a voltage output that is a fraction of the input voltage. It consists of two resistors connected in series across the input voltage, and the output voltage is taken from the connection point between the two resistors. online Voltage Divider Calculator

*V*out=*V*in×(*R*1/*R*2+*R*2)

Where:

*V*in is the input voltage (Vs).*R*1 is the resistance of the first resistor.*R*2 is the resistance of the second resistor.

The ratio *R*1/*R*2+*R*2 determines how much of the input voltage is dropped across the second resistor, thus determining the output voltage. By choosing appropriate resistor values, you can create different output voltage levels from a given input voltage. This principle is widely used in various electronic circuits for voltage scaling and signal conditioning purposes.
