5-Band Resistor Color code

5-Band Resistor Color code

Band 1: Select the color Black (0) Brown (1) Red (2) Orange (3) Yellow (4) Green (5) Blue (6) Violet (7) Gray (8) White (9)

Band 2: Select the color Black (0) Brown (1) Red (2) Orange (3) Yellow (4) Green (5) Blue (6) Violet (7) Gray (8) White (9)

Band 3: Select the color Black (0) Brown (1) Red (2) Orange (3) Yellow (4) Green (5) Blue (6) Violet (7) Gray (8) White (9)

Multiplier: Select the color Black (1 Ω) Brown (10 Ω) Red (100 Ω) Orange (1 kΩ) Yellow (10 kΩ) Green (100 kΩ) Blue (1 MΩ) Violet (10 MΩ) Gold (0.1 Ω) Silver (0.01 Ω)

Tolerance: Select the color Brown (±1%) Red (±2%) Green (±0.5%) Blue (±0.25%) Violet (±0.1%) Gray (±0.05%) Gold (±5%) Silver (±10%)

Resistance Value:



Calculate

Click Here for 4 Band Color

Click Here for 3 Band Color

Here’s how this calculator Works lets finds.

1. First Band: Represents the first significant digit.
2. Second Band: Represents the second significant digit.
3. Third Band: Represents the third significant digit.
4. Fourth Band: Represents the multiplier.
5. Fifth Band: Represents the tolerance.

The color codes for the digits, multiplier, and tolerance are as follows:

• Black: 0, x10^0
• Brown: 1, x10^1, ±1%
• Red: 2, x10^2, ±2%
• Orange: 3, x10^3
• Yellow: 4, x10^4, ±4%
• Green: 5, x10^5, ±0.5%
• Blue: 6, x10^6, ±0.25%
• Violet: 7, x10^7, ±0.10%
• Gray: 8, x10^8, ±0.05%
• White: 9, x10^9
• Gold: x10^-1, ±5%
• Silver: x10^-2, ±10%123

Here is an Example A 5-band resistor with the colors brown, green, black, orange, and red can be decoded like this:

1. First Band (brown): 1st significant digit = 1
2. Second Band (green): 2nd significant digit = 5
3. Third Band (black): 3rd significant digit = 0
4. Fourth Band (orange): Multiplier = x10^3 (1k)
5. Fifth Band (red): Tolerance = ±2%
   So, the resistance will be: 150 * 1k = 150k Ohms with ±2% tolerance

Thank you very much for Using our tools
